Specification
Standard | SMS,DIN |
Material | Silicone, EPDM, PTFR, etc. | Provided with material inspection report |
Size | 1/4"- 8", DN10 - DN200 |
Availabe Connection | Clamp,Union |
Color | Any color as per requested |
Customized | OEM |
Packaging Details | Shrink wrapped - carton - pallet. Or as per the request of customers |
Application | Stainless steel pipeline system with ferrules, clamps, end caps,valves, unions, sight glass etc. |
Sealing ring also pays attention to the following conditions
1.Flexibility and elasticity.
2.Appropriate mechanical strength, including tensile strength, elongation and tensile strength etc.
3.Stable performance, easy to swelling in the medium, heat shrinkage (Joule effect) small.
4.Easy processing, and can keep theprecision dimension.
5.No corrosion no pollution to medium contact surface, etc.
Advantage of Sanitary Gasket
1.The sealing ring in the work pressure and temperature range, good sealing performance, and with the increase of pressure can improve the sealing performance.
2.The friction between the sealing ring and the moving parts of the device must be small, stable friction coefficient.
3.The corrosion resistance of the sealing ring is strong, not easy to aging, long service life, good resistance to abrasion, wear can automatically compensate to some extent.
4.Has the advantages of simple structure, convenient use and maintenance, the sealing ring has a longer life.
How to Order ?
1. What material? Such as EPDM, Slicone, PTFE, etc.?
2. What size? Such as 1/4"- 8", DN10 - DN200?
3. What connection? Such as clamp,union?
4. What quantities?
