Specification
Standard | DIN |
Material Contact Parts | SS316L, SS304 | Provided with material inspection report |
Size | DN15, DN25, DN40, DN50 |
Connection | Tri-clamp |
Flow | 4-100000L/H |
Pressure | ≤1Mpa |
Clamp Size | 50.5MM,64MM |
Alarm | With, Without |
Model | LZB-K30 |
Advantage
1.Glass rotameters have a simple structure with low purchase and maintenance costs.
2.Flow rate can be read directly via transparent tube without power supply.
3.They suit various gases and liquids and bring slight pipeline pressure loss.
4.Parts replacement is easy for convenient daily maintenance.
How to Order ?
1. What material? For example, SS304, SS316L.
2. What traffic? For example, 0-6000LPH.
3. What size? For example, 2Inch.
