Specification
Standard | SMS,DIN |
Material Contact Parts | SS304/SS316L(1.4301/1.4404) | Provided with material inspection report |
SS304(1.4301) |
Size | 1” to 4”，DN25 to DN100 |
Connection | Butt-weld,Tri-clamp,Male Thread,Female-Male Threaded,Union,Weld-Thread,Flange |
Seal Material | Silicone,EPDM,PTFE.All seals material comply with FDA21CFR117.2600 |
Media | Liquid,Gas |
Power Option | Manual,Pneumatic,Manual-Pneumatic |
Working Pressure | ≤12bar(174psi) |
Supply Pressure for Air Actuator | 5~8(72.52psi~116psi) |
External Surface Treatment | Ra32~64uin(0.8~1.6um) |
Internal Surface Treatment | Ra16~32uin(0.4~0.8um) |
Highlights at a glance
* Sanitary Grade Construction: Ensures hygiene for food and beverage applications.
* Adjustable Design: Accommodates various pressure relief needs.
* High-Quality Stainless Steel: Durability and resistance to corrosion.
* EPDM Seals: Reliable sealing performance for long-term use.
* Manual Operation: Easy to install and maintain.
Operating Principle
Under normal operating conditions, the valve remains closed.
When the pressure in the pipes is above the specific pressure, the valve becomes open automatically to make the liquid pass over in order to reduce the pressure in the pipes.
Design Features
1.Featuring Simple Structure,Attractive Appearance,Convenient Maintainance
2.Adjutable Pressure Control
3.Acid-proof Stainless Steel Valve Body,Bright and Clean Surface,Food Rubber Seat,The Product Meet Sanitary Requirement.
How to Order Sanitary Safety Valve?
1. What's products used for safety valves?
2. What's material? Such as SS304, SS316L.
3. What's available size? Such as 1inch to 4inch, DN25 to DN100.
4. What's pressure setting? Such as 2.2bar.
5. What's connection ends? Such as clamp, butt-weld, male threaded.
6. What's kind of power option? Such as manual, pneumatic, manual and pneumatic.
