Specification
Standard | SMS,DIN |
|
Material Contact Parts | SS304(1.4301)/SS316L (1.4404) | Provided with material inspection report |
|
Material Non-contact Parts | SS304(1.4301) |
|
Size | 1/2 to 4 inch, DN10 to DN100 |
|
Body Combination | Straight Two Ways, Three Ways T port, Three Ways L port |
|
Connection | Butt-weld, Tri-clamp, Male Thread, Union, Flange |
|
Seal Material | PTFE Seal. The seal material comply with FDA21CFR117.2600 |
|
Power Option | Manual Operated |
|
SS Pneumatic Actuator, Aluminum Pneumatic Actuator, Electric Actuator |
|
Working Pressure | ≤10bar(145psi) |
|
Supply Pressure for Air Actuator | 5~8(72.52psi~116psi) |
|
Internal Surface Treatment | Ra16~32uin(0.4~0.8um) |
|
External Surface Treatment | Ra32~64uin(o.8~1.6um) |
|
Design Features
1.Various standards can be provided: SMS,DIN
2.Available in sizes from 1/2”-4”, DN10-DN100
3.Seals comply with FDA 21CFR 177. 2600.
4.The valve body can be customized with a wide selection of different connections.
Advantages
1.Free of maintenances
2.Compact and portable
3.Small operating to request
4.Gasket complies with PTFE FDA 177.2600
5.Handle level can be installed on the side of valves body, no matter of the flow direction.
Highlights at a glance
* Stainless Steel Construction: Durability and resistance to corrosion.
* Tri-Clamp Design: Easy installation and maintenance.
* 1-inch Connection Size: Suitable for various industrial applications.
* Manual Operation: No need for electricity or pneumatic power.
* FDA Compliant Seal: Ensures safe handling of food-grade materials.
Options
1.Connection can be Butt-weld,Tri-clamp,Male Thread,Union,Flange or others upon request.
2.Power operated: Manual,SS Pneumatic Actuator, Aluminum Pneumatic Actuator, Electric Actuator.
3.Body Combination:Straight Port, T Port, L Port.
How to Order ?
1. What's standard? Such as DIN, SMS.
2. What's material quality? Such as SS304 and SS316L for optional.
3. What's size? The available size is from 1/2inch to 4inch, DN15 to DN100.
4. What type of ball valve? Such as straight two ways, three ways T port, three ways L port.
5. What's connection end? Such as butt-weld, tri-clamp, male threaded, female threaded, union, ect.
6. What's working principle? such as manually, SS pneumatic actuator, aluminum pneumatic actuator, electrical Actuator.
