The Details of Product
Material Contact Parts | SS304/SS316L(1.4301/1.4404) | Provided with material inspection report |
Material Non-contact Parts | SS304(1.4301) |
Flow Rate | 1.5-130 m³/hr |
Motor Power | 1.5-132 KW |
Voltage | 380v,220v, 230v, 208v, 460v, 440v, 415v, 400v |
Hertz | 50hz, 60hz |
Phase | Single Phase, Three Phases |
Speed | 2900rpm, 3500rpm, 1450rpm |
Motor Brand | China motor |
Type of Teeth | Rough Teeth, Middle Teeth, Fine Teeth |
Processing Method | Mixing→Dispersing→Emulsifying→Homogenizing |
Material of Mechanical Seal | Alloy + Viton & Alloy + EPDM for Double Mechanical Seal |
Connection | Butt-weld, Ferrule End, Male Thread, Female-Male Threaded, Union, Weld-Thread, Flange |
Seal Material | Silicone,EPDM, all seals material comply with FDA21CFR117.2600 |
Working Pressure | ≤10bar(145psi) |
Supply Pressure for Air Actuator | 5~8(72.52psi~116psi) |
External Surface Treatment | Ra32~64ui n(o.8~1.6um) |
Internal Surface Treatment | Ra16~32uin(0.4~0.8um) |
Selection of Configuration for One-stage High Shear Dispersing Homogenizer Pump
1. Ordinary Variable Frequency Motor or Variable Frequency Motor or Ordinary Motor
2. FVD Frequency Converter Control Box, such as Delta Brand or Brand or Other Brands
3. Cabinet Mobile Cart with Brake or without Brake
4. With Hopper, such as 40L Hopper, 50L Hopper
5. With Tanks
Advantage
1. Mass production suitable for continuous production of industrialized assembly line
2. Small diameter range,and highly even
3. Time saving,highly efficient and energy saving
4. Low noise,stable operation
5. Reduced quality difference between lots
6. Material is fully dispersed snd sheared
7. Daliver in short distancc with low lift
8. Easy operation,convenient maintenance
9. Automatic control
How to Order?
1. What's material quality? Such as SS304 or SS316L.
2. What's products used for pump? Such as cosmetic.
3. What's viscosity of products? Such as 10000cps.
4. What's flow rate per hour? Such as 3000 liters per hour .
5. What's head for pump? Such as 2.2kw.
6. What's voltage and hertz? Such as 380v/50hz/ 3phase.
7. What's type of motor brand? Such as China motor.
8. How many quantity you need?
