The Details of Product
Material Non-contact Parts | SS304(1.4301) |
Material Contact Parts | SS304/SS316L(1.4301/1.4404) |
Flow Rate |
1.5-130 m³/hr |
Motor Power | 1.5-132 KW |
Connection | Butt-weld, Ferrule End, Male Thread, Female-Male Threaded, Union, Weld-Thread, Flange |
Material of Mechanical Seal | Alloy + Viton & Alloy + EPDM for Double Mechanical Seal |
Voltage | 380v,220v, 230v, 208v, 460v, 440v, 415v, 400v |
Hertz | 50hz, 60hz |
Speed | 2900rpm, 3500rpm, 1450rpm |
External Surface Treatment | Ra16~32uin(0.4~0.8um) |
Internal Surface Treatment | Ra16~32uin(0.4~0.8um) |
Advantage
1. Mass production suitable for continuous production of industrialized assembly line
2. Small diameter range,and highly even
3. Time saving,highly efficient and energy saving
4. Low noise,stable operation
5. Reduced quality difference between lots
6. Material is fully dispersed snd sheared
7. Daliver in short distancc with low lift
8. Easy operation,convenient maintenance
9. Automatic control
Design Features
1. The flow is designed in 1.5 to 130 m³/hr
2. Motor power can be matched from 1.5 kw to 132 kw
3. The teeth can be designed to rough teeth, middle teeth and fine teeth
How to order?
1. What's material quality ? Such as SS304 or SS316L
2. What's products used for pump ? Such as cosmetic
3. What's viscosity of products ? Such as 10000cps
4. What's flow rate per hour ? Such as 3000 liters per hour
5. What's head for pump? Such as 2.2kw
6. What's voltage and hertz ? Such as 380v/50hz/ 3phase
7. What's type of motor brand? Such as China motor
8. How many quantity you need ?
