KSCP-10-24-2.2 High-Eficiency Sanitary Hygienic Stainless Steel Food Grade SS304 Centrifugal Pump with Open lmpeller

You are here: Home » Products » Sanitary Pumps » Sanitary Centrifugal Pump » KSCP-10-24-2.2 High-Eficiency Sanitary Hygienic Stainless Steel Food Grade SS304 Centrifugal Pump with Open lmpeller

Share to:

KSCP-10-24-2.2 High-Eficiency Sanitary Hygienic Stainless Steel Food Grade SS304 Centrifugal Pump with Open lmpeller

The stainless steel centrifugal pump is an efficient and reliable liquid transportation device, specially designed for fields such as food, pharmaceuticals, chemicals, and environmental protection. It achieves stable flow and pressure through the high-speed rotation of the impeller, and is suitable for various media including clean water, chemicals, and high-temperature liquids. The stainless steel material (such as SS304, SS316L) ensures the pump's corrosion resistance and hygiene performance. The centrifugal pump has a simple structure, is easy to maintain, and offers advantages such as high efficiency, energy saving, long service life, and economic practicality. It is an ideal choice for the field of liquid transportation.

Model:
KSCP-10-24-2.2
Brand:
XUSHENG
Code:
0201101A01112040305

Availability:

Quantity:



Inquire Add to Basket

The Details of Product

Material contact parts	SS304，SS316L (1.4301，1.4404)	Provided with material inspection report
Non-contact parts	SS304 (1.4301)
Sealing gasket	Silicone, EPDM, Nitrile rubber, FPM (fluoro-rubber) and PTFE
Maximum traffic	130m³/h
The largest head	70 meters (7 bar)
Motor power	0.55 kW ~ 30 kW
Automobile Brand	Siemens, China Automobile
Maximum speed	3600 rpm, 2900 rpm, 1400 rpm
Voltage	110V、220V、380V、440V
Motor frequency	50 Hz, 60 Hz
Hertz type	Single phase, three phase
Available connections	Fixtures, joints, flanges, threaded accessories
Mechanical seal	SIC/C/EPDM (standard), alloy material
Mechanical seal type	Single mechanical seal, double mechanical seal
Impeller type	Open impeller, closed impeller, semi-open impeller
Temperature	-20 °C ~ 140 °C

Description of Commodity: KSCP-10-24-2.2 High-Eficiency Sanitary Hygienic Stainless Steel Food Grade SS304 Centrifugal Pump with Open lmpeller

Advantages of the product

1. The pump comprises an electric motor and is made of stainless steel, not only has a highly clean exterior and interior design, but can also be flushed by in-line high pressure water.

2. This pump has technical characteristics such as high emission, low noise, high flow, no dead corners, and high efficiency. Comply with ASME BPE and EHEDG high standards. Certification 3A-02-10, ce-md/06/42/EC

Features of the product

Simple structure, easy to disassemble, adjustable foot height, anti-vibration device, low noise, high efficiency, long-term normal operation, easy maintenance, gentle and delicate treatment, this sanitary centrifugal pump series is your ideal choice. It meets food hygiene standards and ensures the authentic flavor of your products.

Product application

Pumps are mainly used in: mainly used in pharmaceutical, alcohol, food and chemical industry and beverage industries, and transport liquids with high pressure and high pressure filtered smaII flow.

Product production process

Order raw materials → Raw material processing → Accessories assembly → Motor installation → Semi-finished products → Test performance → Screw fasteners → Visual testing & functional testing → Packaging → Final inspection

How to Order about Centrifugal Pump ?

1. What's material quality? Such as SS304 and SS316L for optional

2. What's flow rate for centrifugal pump, such as 1500 liters per hour?

3. What's head, such as 14 meters?

4. What's motor power, such as 0.55kw?

5. What's voltage and hertz, such as 380v, 50hz, three - phase?

6. What's motor brand, such as ABB motor?

7. What's connection end? Such as butt - weld, tri - clamp, male threaded, female threaded, union, ect.

8. What's design temperature and working temperature for pump?

9. Do you need single mechanical seal or double mechanical seal?

10. Type of impeller, such as open impeller, close impeller, semi - open impeller?
