Stainless Steel Sanitary Mannual Flow Regulating Valve
You are here: Home » Products » Flow Division Valve » Flow Control Valve » Stainless Steel Sanitary Mannual Flow Regulating Valve
Share to:

Stainless Steel Sanitary Mannual Flow Regulating Valve

The valve is a sanitary constant pressure valve which can be used in food-processing, beverage, biopharmaceutical.]
It has two kinds of keeping constant pressure:V type (inlet constant pressure); maintain constant pressure at the valve inlet. Such
desifn is specially applied at the back of heat-exchanger. It is used as safety valve.A type (outlet constant pressure);
maintain constant pressure at the outlet. Such design is used as the front of filling machine and bottle filling machine.

  • Dn32-Dn50,1 1/2"-2",38mm-51mm
  • XUSHENG
  • D10000010001
Quantity:
Material Pressure≤10bar
Temperature Range-10 celsius degree-+150 celsius degree
Compressed Air Pressure0~8bar
Max Particle Size0.01mm
Max Oil Content0.08ppm
Dew PointAtmospheric Temperature 10 celsius degree or low
Max Water Content7.5g/kg
SizeDN32-DN50,1 1/2"-2",38MM-51MM
Standard AvailableDIN,3A,SMS,ISO
Material QualitySs304, Ss304L ,Ss316, Ss316L
