Main Parameter
Standard | SMS,DIN |
Material Contact Parts | SS304(1.4301)/SS316L (1.4404) | Provided with material inspection report |
Material Non-contact Parts | SS304(1.4301) |
Application | Powder, Particle, Capsule |
Size | 4 to 12", DN1100 to DN300 |
Connection | Butt-weld,Tri-clamp,Male Thread,Female-Male Threaded,Union,Weld-Thread,Flange |
Seal Material | Silicone,EPDM,FKM,Buna,All seals material comply with FDA21CFR117.2600 |
Drive Option | Manual Stainless Steel Handle |
SS Pneumatic Actuator (air/spring, air/air) |
Aluminum Pneumatic Actuator (air/spring, air/air) |
Electric Actuator (on-off, adjustable) |
Drive Option | C-top Controller, C-top Controller (AS-I) |
Max. Working Pressure | ≤16bar (232psi) |
Min. Working Pressure | 0.2bar (2.9psi) |
Supply Pressure for Air Actuator | 5~8 (72.52psi~116psi) |
External Surface Treatment | Ra32~64uin(0.8~1.6um) |
Internal Surface Treatment | Ra16~32uin(0.4~0.8um) |
Temperature range | -20~130 ºC (up to Seat Seal) |
Certificate | ISO 9001, FDA, SGS, CE |
Options
1.The gasket can be Silicone, EPDM, FKM,Buna. All seals material comply with FDA21CFR117.2600
2. Connection can be butt weld,tri clamp,flanged or others upon request.
3. Drive option can be manual, SS pneumatic actuator, aluminum pneumatic actuator, electric actuator
Design Features
1. Various standards can be provided: SMS,DIN
2. Available in sizes from 4to 12",DN100 to DN300 3.Pneumatic actuator and electric actuator are i
nterchangeable.
4.Pneumatic actuator can be double acting or single acting
5. Seals comply with FDA 21CFR 177. 2600. 6.The valve body can be customized with a wide selection of different connections.
Advantages
1.Ultra small frictional force
2.Ultra long working life
3.Ultra easy to be cleaned
4.Ultra easy to be disassembled
5.Adjustable pressure
6.High Precision
7.Discharged homogeneously
How to Order ?
1. What's products used for powder butterfly valves?
2.What's standard for butterfly valve? Such as DIN, SMS
3.What's material quality? Such as SS304 and SS316L for optional
4.What's size? The available size is from 4inch to 12inch, DN100 to DN300
5.What's connection end? Such as Butt Weld, Tri Clamp, Flanged
6.What's working principle, such as manual, pneumatic, control head ?
7.What's material of seal, such as silicone, EPDM ?
