The deposition tank consists of a standard oval head, conical bottom and paddle stirrer. The impurities are separated by freezing and sedimentation at room temperature or low temperature to improve the purity and clarity of the Chinese medicine extract. The tank is equipped with an automatic rotating spray head, low temperature cooling water can be passed through the jacket, mechanical seals are used in the transmission parts, and explosion-proof motors ensure production safety.
What is the function of the deposition tank?
What are the characteristics of deposition tank equipment?
What are the product features of the deposition tank?
The deposition tank is suitable for alcohol precipitation of traditional Chinese medicine, oral liquid, food, health care products, chemical industry, etc. The alcohol precipitation tank is a special equipment developed by the old process of alcohol precipitation (also known as solvent exchange or alcohol rod), mainly used for the concentration of traditional Chinese medicine decoction The post-concentration can be used for the operation of freezing irrigation and alcohol precipitation, and the post-extraction concentrate of traditional Chinese medicine can also be used for water precipitation.
The deposition tank consists of a jacketed oval head. The cylindrical body with conical bottom is assembled with three-blade stirring and special fine-tuning rotating liquid pipe. The traditional Chinese medicine is decoction and concentrated by adding alcohol to make a liquid with a certain degree of alcohol, and then freezing and sedimenting the liquid at room temperature and low temperature. Solid separation to improve the purity and clarity of Chinese herbal extracts. The deposition tanks are all made of stainless steel SUS304, equipped with high-pressure water automatic spray cleaning system, low-temperature cooling water can pass through the jacket, mechanical seals and explosion-proof motors are used in the transmission parts to ensure production safety, in line with GMP medical standards, and the surface of the equipment is mirror or matt deal with.
(1) The interlayer of the large tank is used as an evaporator, and the liquid ammonia is directly evaporated in the jacket, and the latent heat of vaporization is used to cool the beer liquid in the tank, thereby eliminating the intermediate heat exchange cycle of alcohol water and saving energy consumption by more than 12%.
(2) The jacket is used as an evaporator. Because the pressure in the jacket is higher than that of the alcohol water system, a safe, reliable, reasonable and novel honeycomb structure jacket is set up. structure, the strength and stiffness of which are mutually improved. Jacket welds can be reduced by 30%.
(3) The jacket is made of pieces, and the welding with the cylinder body completely avoids the longitudinal and circumferential welding seams of the cylinder body, avoiding the possibility of ammonia leaking into the beer liquid in the tank through the welding seam. The deposition tank overcomes the disadvantages of other jackets.
⑷The deposition tank can be made of carbon steel or stainless steel, which is convenient for on-site manufacturing, reduces manufacturing costs and saves investment costs.
Wenzhou Xusheng Machinery Industry and Trading Co., Ltd has various deposition tank that can provide the increasing of products, and make them more effective, reliable, and consistent.
