Main Parameter
Material: | SS304,SS316L |
Standard: | DIN,SMS,ISO,IDF |
Size: | 1"-3"/DN25-50 |
Connection Way: | Weld, Clamp,Thread,Union |
Temperature of Media: | Normal Temperature |
Pressure: | 1-6Bar |
Operated: | Pneumatic |
Working principle
The radial pressure gauge displays pressure by the elastic deformation of sensitive components (Bourdon tube, bellows, bellows) inside the gauge, and then the pressure deformation is transmitted to the pointer by the conversion mechanism of the movement inside the gauge, causing the pointer to rotate to display pressure
Purpose
The use of radial pressure gauges is extremely common, covering almost all industrial processes and scientific research fields. Pressure gauges are widely used in thermal pipelines, oil and gas transmission, water and gas supply systems, vehicle maintenance and repair shops, etc. It is mainly used to measure the pressure of the medium
Feature
* Available in dead weight or spring loaded design
* Fast acting, quick opening
* Gas tight design
* Choice of materials as per the fluid medium.
* From 1 ½" to 2" size
* Economically priced
How to order pressure gauge?1.What's material, such as SS304 or SS316L ?
2.What are the maximum and minimum ranges of a pressure gauge? Such as, 0~1MPa, 0~10Bar
3.What is the medium being measured? Such as gases, liquids, vapors, corrosive media, etc
4..What is the required precision? Such as ±1.0%,±0.5%,±0.25%
