Main Parameter
Stanadrd | SMS, DIN |
Body Material | SS304, SS316L |
Available Size | DN50-DN300 |
Glass Material | Heavy Wall Borosilicate (Pyrex)Tubing, Polycarbonate(bing,
Acrylic Tubing, Tempered Glass |
Gasket Material | Silicone, EPDM, NBR, FKM |
Protection Lens Cove | Polycarbonate Tubing,Acrylic Tubing,Slotted Stainless Steel |
Temperature Range | Minus 20degree Celsius~135degree Celsius |
Pressure Range | 0bar~10bar |
Working Pressure | 6bar |
Inside and Outside(Mirror Finish) | RA ≤ 0.8um |
Inside and Outside Electrolytic Polishing | RA ≤ 0.8um |
Spare Parts | With Wiper or Without Wiper |
Warrenty | One Year |
Support | OEM, ODM Are Welcome |
Application | Food-Processing, Beverage, Beer, Pharmaceutical |
Machine Processing | The most advanced CNC machine from Japan for processing |
Main functions and purposes
1.Internal observation and monitoring
2.Fault diagnosis and troubleshooting
3. Safety interlock
..
Main Features
Intuitive and clear
High pressure and high temperature resistance
Corrosion resistance
Good sealing performance
Simple structure, sturdy and durable
Common types
1. Ordinary straight through mirror
2. Mirrors with lights
3. Dual color water level gauge:
4. Float mirror
How to Order Sight Glass?
1.What's material, such as SS304 or SS316L ?
2.Which size, the size is from DN50 to DN200 ?
3. What's pressure rating you need ?
4. Do you need wiper or not ?
5. How many quantity ?
