Main Parameter
Stanadrd | SMS, DIN |
Body Material | SS304, SS316L |
Available Size | DN50-DN300 |
Glass Material | Heavy Wall Borosilicate (Pyrex)Tubing, Polycarbonate(bing,
Acrylic Tubing, Tempered Glass |
Gasket Material | Silicone, EPDM, NBR, FKM |
Protection Lens Cove | Polycarbonate Tubing,Acrylic Tubing,Slotted Stainless Steel |
Temperature Range | Minus 20degree Celsius~135degree Celsius |
Pressure Range | 0bar~10bar |
Working Pressure | 6bar |
Inside and Outside(Mirror Finish) | RA ≤ 0.8um |
Inside and Outside Electrolytic Polishing | RA ≤ 0.8um |
Spare Parts | With Wiper or Without Wiper |
Warrenty | One Year |
Support | OEM, ODM Are Welcome |
Application | Food-Processing, Beverage, Beer, Pharmaceutical |
Machine Processing | The most advanced CNC machine from Japan for processing |
working principle
Its working principle is very simple: a sealed observation window is formed on the wall of the pressure vessel through high-strength transparent material, and the process information inside the pipeline is directly obtained through artificial vision..
Main Features
1. The surface glass of the window is easy to clean
2. Glass windows allow for 360 degree observation
3. Dual use standing and lying for easy installation
4. Detachable for easy maintenance and cleaning
Main application areas
Glass tube viewing cups are widely used in industrial scenes that require on-site observation:
Boiler system: Observe the boiler water level (which is one of the important safety accessories of the boiler).
Chemical, petroleum, and pharmaceutical industries: observe the liquid level of reaction vessels and storage tanks, or the flow and color of fluids in pipelines.
Food and beverage industry: observe the flow of fluids such as milk, juice, beer, etc.
Water treatment system: Observe the liquid level and water flow of the filter and water tank.
Power and HVAC systems: observe circulating water, refrigerant, etc
How to Order Sight Glass?
1.What's material, such as SS304 or SS316L ?
2.Which size, the size is from DN50 to DN200 ?
3. What's pressure rating you need ?
4. Do you need wiper or not ?
5. How many quantity ?
