Stainless Steel Sanitary Matte Polished Clamping 90 Degree Elbow Bend
You are here: Home » Products » Sanitary Fittings » Sanitary Elbow Bend » Stainless Steel Sanitary Matte Polished Clamping 90 Degree Elbow Bend
Share to:

Stainless Steel Sanitary Matte Polished Clamping 90 Degree Elbow Bend

  • 1"-6",DIN 25-150
  • XUSHENG
  • D10000090019
Quantity:

Technical Parameters

Availably standardSMS,DIN,3A,IDF,RJT, BS, ISO
Material QualitySS304,SS304L,SS316,SS316L
Availabe ConnectionWelding ends,triclamp ends,union ends,male ends
Available Polishing180 Grit ,240 Grit, 320 Grit ,420 Grit,Unpolished
Type of reducerConcentric,Eccentric
Available Thickness1.5MM,1.65MM,2MM,2.5MM,3MM
Sorts of elbowWith/Without straight ends
Temperature Range-20degree Celsius~135degree Celsius
Pressure range0bar~10bar
Inside and outside(mirror finish)RA ≤ 0.8um
Inside(mirror finish) and outside(matt finish)RA ≤ 0.8um
Inside and outside Electrolytic polishingRA ≤ 0.8um
DIN SpecifcationDN20>DN15
DN25>DN20
DN32>DN20
DN32>DN25
DN40>DN20
DN40>DN32
DN50>DN25
DN50>DN32
DN50>DN40
DN65>DN25
DN65>DN32
DN65>DN40
DN65>DN50
DN80>DN40
DN80>DN50
DN80>DN65
DN100>DN50
DN100>DN65
DN100>DN80
SMS Specificaion1 1/2">1"
2">1"
2">1 1/2"
2 1/2">2"
3">2"
3">2 1/2"
4">2"
4">2 1/2"
4">3"
